Ensure unwavering internet connectivity and enhanced network security for your home or small business in Tripoli with the Cudy Gigabit Multi-WAN VPN Router, Model: R700. This robust router is specifically designed to provide maximum internet uptime through its Multi-WAN capabilities, allowing you to connect to multiple internet service providers (ISPs) simultaneously.
With up to four Gigabit WAN ports, the R700 can intelligently distribute internet traffic (load balancing) across available connections, or instantly switch to a backup connection (link backup) in case one fails. This is crucial for businesses in Lebanon where reliable internet is paramount. All ports are Gigabit Ethernet, ensuring high-speed wired connections for your critical devices.
Beyond connectivity, the R700 is a powerful VPN router, supporting a wide array of VPN protocols including WireGuard, OpenVPN, IPSec, PPTP, and L2TP. This enables secure remote access for your employees, protects sensitive data, and allows for building secure site-to-site connections. The integrated ZeroTier support further simplifies remote access and the creation of virtual private networks.
Housed in a compact and durable metal casing, the R700 is built for stable and continuous operation. It offers advanced network management features like Internet Access Control (MAC/IP/URL Filtering), QoS (Rate Limiting), and comprehensive firewall protection (SPI, DoS), providing a secure and controlled network environment for your operations.
Key Benefits for Businesses in Lebanon:
Key Features:
Feature | Specification |
Model | R700 V1.0 |
Ethernet Ports | 5 x Gigabit RJ45 Ports: |
1 x Dedicated Gigabit WAN Port | |
3 x Gigabit WAN/LAN Configurable Ports | |
1 x Dedicated Gigabit LAN Port | |
CPU | MediaTek MT7621DAT (880 MHz Dual-Core MIPS1004Kc) |
Memory | 16 MB NOR Flash / 128 MB DDR3 RAM |
Multi-WAN | Up to 4 WAN Ports, Load Balancing (Online Detection, Weighted Diversion, Reply to Origin), Link Backup |
VPN Support (Client & Server) | WireGuard, OpenVPN, IPSec, PPTP, L2TP, ZeroTier |
Max Concurrent VPN Tunnels | IPSec: 20; PPTP/L2TP: 16; OpenVPN: 16 |
VPN Performance (Typical) | WireGuard Client: ~142 / 234 Mbps (UL/DL); WireGuard Server: ~213 / 152 Mbps (UL/DL) |
OpenVPN Client: ~22 / 25 Mbps (UL/DL); OpenVPN Server: ~22 / 21 Mbps (UL/DL) | |
Firewall | SPI Firewall, DoS Protection, Block PING from WAN, MAC Filtering, IP Filtering, Domain Filtering |
Routing | Static Routing, Policy Routing |
QoS (Quality of Service) | Rate Limiting, Session Limit |
DNS | DNS over TLS (Cloudflare, Google, Quad9, Custom), Manual DNS, DNS Rebind Protection |
Max Concurrent Sessions | 15,360 (or 25,000 in some documents) |
Operating Modes | Router (Multi-WAN Router) |
Management | Web UI (HTTP/HTTPS), TR069, Cloud Control |
Casing Material | Metal |
Installation | Desktop, Wall-Mounting |
Power Supply | External 12V / 1A DC Adapter (Included) |
Max Power Consumption | ~6W - 9W |
Dimensions (L x W x H) | 119 × 85 × 28 mm (4.69 × 3.35 × 1.1 inches) |
Operating Temperature | 0°C ~ 40°C (32°F ~ 104°F) |
Certifications | FCC, CE |
