Gigabit media converter with POE, 1 port fiber and 1 port POE

Full Product Description

Gigabit Single-Mode SC Fiber Media Converter with PoE+ Injector – 20 KM, 1310 nm, 30 W PoE

This Gigabit Fiber Media Converter with integrated PoE/PoE+ injector combines fiber-to-Ethernet conversion and PoE power delivery in one compact device. It is designed to extend a Gigabit Ethernet connection over single-mode fiber up to 20 km (12.43 miles) while supplying up to 30 W of PoE power to a compatible network device through the RJ45 port.

The converter operates as PSE (Power Sourcing Equipment) and supports IEEE 802.3af PoE (up to 15.4 W) and IEEE 802.3at PoE+ (up to 30 W). This eliminates the need for a separate PoE injector or PoE switch at the remote fiber location, making it ideal for powering IP cameras, wireless access points, VoIP equipment, and other compatible PoE devices.

Key Features

* Media Converter + PoE Injector in One Device
* Fiber Type: Single-Mode Fiber
* Fiber Connector: SC
* Optical Wavelength: 1310 nm
* Maximum Fiber Distance: 20 km / 12.43 miles
* Fiber Standard: 1000BASE-LX
* Ethernet Port: 1 × RJ45
* Ethernet Speed: 10/100/1000 Mbps Auto-Sensing
* PoE Output: Up to 30 W
* PoE Standards: IEEE 802.3af / IEEE 802.3at PoE+
* PSE Device: Supplies power to compatible powered devices
* LFP – Link Fault/Link Loss Propagation: Supported
* Jumbo Frames: Supported
* VLAN Tagged Packets: Transparent transmission
* Duplex Modes: Full/Half Duplex
* Rear DIP Switches: 4-position DIP switch block, including support for forcing 10 Mbps operation for compatible legacy applications
* Converter Input Voltage: 47–57 VDC
* Included Power Supply: 48 VDC, 1.25 A
* Dimensions: 94 × 70 × 26 mm
    (3.70 × 2.76 × 1.02 in)
* Operating Temperature: 0°C to 60°C
* Relative Humidity: Up to 95%, non-condensing
* Management: Unmanaged / Plug-and-Play

Long-Distance Fiber + PoE Solution

Standard copper Ethernet is generally limited to approximately 100 meters. This converter allows the network connection to be extended over single-mode SC fiber for distances up to 20 km, then converts the fiber connection back to Gigabit Ethernet while simultaneously providing PoE power to the connected device.

This makes it particularly useful when a network device needs to be installed far away from the main network infrastructure.

LFP & Jumbo Frame Support

Link Fault Propagation (LFP) helps ensure that a failure on the fiber side is reflected on the Ethernet side, allowing connected network equipment to recognize that the link has been interrupted instead of maintaining a misleading active Ethernet link.

The converter also supports Jumbo Ethernet frames and transparently passes VLAN-tagged traffic, making it suitable for many professional networking and surveillance installations.

Typical Applications

Ideal for:

* IP CCTV cameras
* PoE surveillance systems
* Wireless access points
* Building-to-building network links
* Campus networks
* Industrial networking
* Remote network equipment
* Long-distance fiber installations
* VoIP and other compatible PoE devices

Package Contents

The package includes the Fiber Media Converter with PoE, an external 48 VDC / 1.25 A power adapter, rubber feet, and user documentation.

Important: This version uses SC single-mode fiber at 1310 nm. For a successful fiber link, the device at the opposite end must use a compatible fiber type, wavelength, connector/interface, and Ethernet standard
